Aluminum L foot Fin Tube

L Fin Tubes, L Type Fin Tube, L Foot Fin Tube

Fabrication of L fin tubes

The aluminum fin strip or the copper fin strip is folded into an L shape and spirally wound tightly under the action of tension on the outer surface of the base tube. Tension in the fin strip is wrapped around the tube serves to make the fin foot forcefully on the tube, thus hold the fin firmly in place.

L Finned Tube is combined with two different materials

Core Tube: Carbon steel, stainless steel, copper

Fins: Aluminum, copper, steel

Features:

1. Adopting winding process, high production efficiency

2. Uniform fin pitch, good heat transfer performance

3. Core tube is protected from air corrosion by base of fin

Maximum Working Temperature: 230°C

Application

1. Air cooler in petrochemical, power plant, paper-making, tobacco and building heating.

2. Air heater in food processing equipment

3. Air heater in plant protein and starch spay drying system
