ISO Standard L Type Wrapped Around Fin Tube Seamless OD 19.05mm

Place of Origin: Jiangsu, China
Minimum Order Quantity: Customized
Packing Details: Strong plywood case with steel frame
Delivery Time: Usually 45 days from deposit received date
Product description：Quality L/LL/KL Type Fin Tube manufacturers & exporter - buy L Type Wrapped Around Fin Tube Seamless OD 19.05mm ISO Standard from China manufacturer
INQUIRY

L Type Wrapped Around Fin Tube Seamless OD 19.05mm

Tube material: SA213 TP304 SIZE:OD19.05mm * 1.25mm THK * 3633mm LG
Fin Material: AL1060; OD38.1mm X 275.6FPIX 0.4 mm THK

Manufacturing Process:
The fin is wrapped around the tube and secured at each end. Gives some surface protection to thetube. Used for moderate temperature cooling applications.
Upper temperature limit: 120°C
